VG95234D-22-15SN
CA3106E22-15SB-F80
TR95234D-22-15SN
Straight plug with endbell, cable clamp and telescoping bushing.
VG95234D-22-15SN
Product Features
| Filter Name | Value |
|---|---|
| Connector Type | Plug |
| Connector Shell Style | Straight Plug |
| Connector Endbell Type | Cable Clamp |
| Shell Stytle | D |
| Number of Contacts | 6 |
| Contact Gender | Socket |
| Shell Size | 22 |
| Shell Material | Aluminium |
| Shell Plating | Cadmium Olive Drab Over Electroless Nickel |
| RoHS | N |
Catalogs
Contact Info
|
Contact |
Contacts |
Angular position of the contact inserts in degrees |
||
|
Number |
Size |
|||
|
Metric |
AWG |
|||
|
22-15 |
5 |
25 |
12 |
N (0°) |
|
1 |
15 |
16 |
||
Contact Layout (front face of pin illustrated)
