CIR00SB36B-12PX-F80
TR95234N1-36B-12PX
Shielded receptacle with endbell for shielding braid, and heat shrink boots. Style N1 with 4 threaded holes.
Ürün Özellikleri
| Filtre Adı | Değer |
|---|---|
| Connector Type | Receptacle |
| Connector Shell Style | Wall Mounting Receptacle |
| Connector Mounting Type | Rear Mount |
| Connector Endbell Type | Shielded |
| Shell Stytle | N1, N2 |
| Number of Contacts | 12 |
| Contact Gender | Pin |
| Shell Size | 36 |
| Shell Material | Aluminium |
| Shell Plating | Cadmium Olive Drab Over Electroless Nickel |
| RoHS | N |
Kataloglar
Contact Info
|
Contact |
Contacts |
Angular position of the contact inserts in degrees |
||
|
Number |
Size |
|||
|
Metric |
AWG |
|||
|
36B12 |
3 |
160 |
4 |
X (110°) |
|
3 |
100 |
8 |
||
|
3 |
25 |
12 |
||
|
3 |
15 |
16 |
||
Contact Layout (front face of pin illustrated)
