VG95234N2-32-15SN
CA3100E32-15SB-05-15
TR95234N2-32-15SN
Shielded receptacle with endbell for shielding braid, and heat shrink boots. Style N2 with 4 entry holes.
VG95234N2-32-15SN
Ürün Özellikleri
| Filtre Adı | Değer |
|---|---|
| Connector Type | Receptacle |
| Connector Shell Style | Wall Mounting Receptacle |
| Connector Mounting Type | Rear Mount |
| Connector Endbell Type | Shielded |
| Shell Stytle | N1, N2 |
| Number of Contacts | 8 |
| Contact Gender | Socket |
| Shell Size | 32 |
| Shell Material | Aluminium |
| Shell Plating | Cadmium Olive Drab Over Electroless Nickel |
| RoHS | N |
Kataloglar
Contact Info
|
Contact |
Contacts |
Angular position of the contact inserts in degrees |
||
|
Number |
Size |
|||
|
Metric |
AWG |
|||
|
32-15 |
2 |
500 |
0 |
N (0°) |
|
6 |
25 |
12 |
||
Contact Layout (front face of pin illustrated)
